COMPLETE EQUIPMENT FOR INDUCTION HEATING

Bar Induction Heating Systems

Bar Heating 150 kW

Heated Material Magnetic Steel
Billet Dimension Limits Ø D, 4HR side D  [mm] 12 - 21
Lenght [mm]  3225 - 6300
Output [kW]   150
Maximum Product Output [kg/hr]  270
Output Billet Temperature [°C]  1250

Bar Heating 250 kW

Heated Material Magnetic Steel
Billet Dimension Limits Ø D, 4HR side D  [mm] 12 - 40
Lenght [mm]  3225 - 6300
Output [kW]   250
Maximum Product Output [kg/hr]  360
Output Billet Temperature [°C]  1250

Bar Heating 500 kW

Heated Material Magnetic Steel
Billet Dimension Limits Ø D, 4HR side D  [mm] 18 - 45
Lenght [mm] 4875 - 6300
Output [kW]   500
Maximum Product Output [kg/hr]  950
Output Billet Temperature [°C]  1250

Bar Heating 750 kW

Heated Material Magnetic Steel
Billet Dimension Limits Ø D, 4HR side D  [mm] 8 - 16
Lenght [mm] 1000 - 3000
Output [kW]   750
Maximum Product Output [kg/hr]  2300
Output Billet Temperature [°C]  940

Contact our Engineering Department with your custom requirements. Examples of mid-frequency bar heaters.

Examples of Bar Heating Systems

Mid-frequency Induction Heater Rods SOP 100/25

Mid-frequency Induction Heater Rods SOP 100/25

Mid-frequency induction heater made for Federal-Mogul Valvetrain s.r.o., Dačice, is used for induction heating of rods with circular cross-section up to required temperature for mechanical cutting of steel rods. more...
Special Mid-frequency Induction Heater SOT 200+40/20

Special Mid-frequency Induction Heater SOT 200+40/20

Special mid-frequency induction heater of rods for eperimental forming made for the University of West Bohemia, for induction heating of steel rods, which is used by university researchers in the development more...
SOT 750/10

SOT 750/10

Mid-frequency Rod Heater, Power Class 750 kW is designed for the induction heating of rods with a circular cross-section made of ferritic spring steel. The heater is equipped with a table that can be shifted forward and back, more...
