This heater is designed for the induction heating of cross-sectionally round steel billets to forging temperatures in order to check the forming technology. It is designed for manual billet placement with the ability to place more billets at one time into the two-level chute. Is it equipped with double heating lanes which can be used together or each individually.
|Heated Material||magnetic steel|
|Billet Dimensions||Ø D, square (one side) D [mm]||25 - 155|
|Length l [mm]||1,2 D - 400|
|Maximum Process Capacity [kg/h]||620|
|Billet Delivery Temperature [°C]||1300|
