This heater is designed for the induction heating of rods with a circular cross-section made of ferritic spring steel. The heater is equipped with a table that can be shifted forward and back, which allows the lining up of the inductor path. The heater is controlled by a Siemens programmable logic controller (PLC). The heater parameters (desired temperature, power level, temperature ranges, employee code, etc) is all set on the PLC display. Any system faults in the induction heating system are also displayed on this screen.
|Heated Material||ferritic spring steel|
|Rod Dimensions||Ø D [mm]||8 - 14,5|
|Length l [mm]||1000 - 3000|
|Maximum Rod Speed [m/s]||0,5|
|Maximum Process Capacity [kg/h]||2300|
|Delivery Temperature [°C]||940|
